TECHSHIP IS A GLOBAL SUPPLIER OF WIRELESS COMPONENTS
Virtual Access (Ireland) Ltd is a telecommunications equipment and solution provider. We offer a range of devices that are used to deliver wired and wireless managed connectivity services for telecommunications operators and large enterprises. Over the years our technology has evolved from TDM and ISDN systems to various broadband technologies including DSL, GSM/GPRS/3G/4G LTE/CDMA450, Ethernet in the First Mile and VoIP. Today, our solutions are delivered into many sectors including Smart Grids, Industrial and Transport Infrastructure, Payment Systems, Retail and Lotteries and WiFi for in-vehicle management connectivity. Our solutions include rugged devices for industrial and harsh environments, dual SIM and dual path routers for IoT and M2M.
All our routers have mobile interface(s) so we require a mini PCI express 3G/4G module.
It’s a standard requirement in our customers solutions to provide mobile interfaces. It allows Virtual Access to provide multiple interface options including fixed and mobile connectivity. With the correct radio module, we can provide a working solution, it’s a must requirement.
Originally it was for Ericsson modules and the partnership continued. Main pro is Techship's understanding of the market and technologies and ability to obtain information from the manufacturer. For the modules we use we get a very good price. We always require help in obtaining modules with unusual LTE band requirements and also if there any support issues. Excellent response and always available.
UMTS Bands: B1 (2100), B8 (900) | MIMO (Multiple-Input Multiple-Output): Yes | LTE Bands: B1 (2100), B3 (1800), B7 (2600), B8 (900), B20 (800DD), B38 (TDD 2600), B40 (TDD 2300) | GSM/EDGE Bands: B8 (900), B3 (1800) | Manufacturer: SIMCom | LTE Region: Europe | FOTA Firmware Updates: No | Form Factor: mPCIe - full size | Technology: LTE - cat 3 | Antenna Connectors: IPEX MHF/U.FL | GNSS: Yes | GNSS technology: GPS, GLONASS | Max DL Speed: 100 Mbps | Max UL Speed: 50 Mbps | Chipset: Qualcomm, MDM9215 | Operating Temperature Range: -30 °C – 80 °C | Driver Support: Windows 7, Windows XP, Windows Vista, Linux, Android, Windows 8, Windows CE, Windows 8.1 | Data Interface: USB 2.0 | Voice Call Support: Yes | GNSS antenna support: Passive, Active 3.05VDC | SIM interface: Through miniPCIe connector | GPIO: Yes | Extended Operating Temperature Range: -30 °C – 80 °C | Audio interface: Digital PCM signal input/output in socket, Digital PCM signal over USB interface | Certification: CE, CE RED | Size: 30x30x2.9 mm
1 PCS PRICE $59.00
Technology / Antenna Frequency: GSM 850/900/1800/1900, UMTS 2100, Wifi/Bluetooth 2400, LTE 790-960/1710-2690 | Mounting method: Connector | Antenna Location: External | Connector Type: SMA-M | Impedance: 50 Ohm | Polarization: Vertical | Max power: 50 W | Width: 21 mm | Length: 157 mm | Height: 157 mm
1 PCS PRICE $7.30
UMTS Bands: B1 (2100), B2 (1900), B26 (850), B8 (900) | MIMO (Multiple-Input Multiple-Output): Yes | LTE Bands: B1 (2100), B2 (1900), B3 (1800), B7 (2600), B8 (900), B20 (800DD), B5 (850) | Manufacturer: Huawei | LTE Region: Europe, Asia | FOTA Firmware Updates: Yes | Form Factor: mPCIe - full size | Technology: LTE - cat 3 | Antenna Connectors: IPEX MHF/U.FL | GNSS: Yes | GNSS technology: GPS, GLONASS | Max DL Speed: 100 Mbps | Max UL Speed: 50 Mbps | Chipset: Qualcomm, MDM9215 | Operating Temperature Range: -20 °C – 60 °C | Driver Support: Windows 7, Linux, Android | Data Interface: USB 2.0 | GNSS antenna support: Passive | SIM interface: Through miniPCIe connector | Audio interface: Digital PCM signal input/output in socket | Certification: CE, RoHS, GCF, CE RED
1 PCS PRICE N/A
/ Michael Burke, Pre Sales Engineering Manager Virtual Access (Ireland) Ltd
Techship is helping customers all over the world to integrate wireless components in their systems and products. Below some of the many customer projects Techship has been involved in and what the customers think about us…
