The S76G is designed & manufactured in a smallest form factor -SiP (System in Package). It integrates with SEMTECH SX1276 and a 32-bit ultra-low power Cortex M0+ MCU (STM32L073x), S76G supports global 863MHz or 928MHz ISM-Bands. Capable of 2-way communication and reach over 16 km (10 miles) distance in our field test. Besides, S76G contains a GPS chip –SONY CXD5603GF which is used to receive GPS/GPS+GLONASS signals for positioning.

The module is delivered with firmware pre-configured to 868 MHz as default but the firmware for 915 MHz support can be loaded. Please contact us if you require this module with the 915 MHz FW pre-loaded.



The AcSiP S76S module support LoRaWAN™ protocol Class: A. It is certified according to LoRaWAN™ Certification V1.0.1 by IMST GmbH. The S76S is capable of 2-way communication and reach over 16 km ( 10 miles ) distance in AcSIP field tests.



This product is designed with multiple easy to use interfaces (I2C/SPI/UART/GPIO), fine-tuned RF performance and will be offered with complete SDK library & ready to go HDK, it can significantly help the users to shrink the size of end device and simplify the development efforts for any LoRa applications.



Evaluation Kit including the AcSIP S76G module can be found here.
