Novatel E346

Article Number: 10016

|

Supplier Number: E346

|

End of Life

Brand

Novatel

Form Factor

mPCIe - full size

UMTS Bands

B1 (2100), B2 (1900), B8 (900), B26 (850)

Max DL Speed

14.4

All Technical Details

Variant description

Download Datasheet

Product Details & Tech Facts

Description

Novatel Wireless' Expedite® E346 PCI Express Mini Card is an embedded module that can be integrated into laptops and other devices for 3G mobile data applications. Powered by the Qualcomm® MDM6200 chipset, the Expedite E346 offers high performance to the user on HSPA+ bands with global fallback to 2G. With the network selection feature, now OEMs only need to stock a single SKU.



3G technology provides data speeds up to 14.4 Mbps from virtually anywhere in the world. The Expedite E346 3G PCI Express Mini Card empowers devices with global mobile broadband connectivity.



The small cost effective Expedite E346 module leverages HSPA+ and GSM technologies. Switching between networks enables your customers to work, play and stay connected anytime, anywhere worldwide.

Form Factor

mPCIe - full size

GNSS technology

Data Interface

USB 2.0

UMTS Bands

B1 (2100) B2 (1900) B8 (900) B26 (850)

Chipset

Driver Support

Linux Windows 7 Windows Vista Windows XP

Max DL Speed

14.4 Mbps

Antenna Connectors

IPEX MHF/U.FL

Max UL Speed

5.76 Mbps

Carrier Certification

AT&T T-Mobile

GNSS

Yes

Operating Temperature Range

-30 - 70 °C
