Telit Cinterion TX62-W-B LTE Cat-M/NB2 LGA

Article Number: 12700

|

Supplier Number: L30960N6650K150

Brand

Telit Cinterion

Form Factor

LGA

Primary Technology

eMTC (Cat-M1), NB-IoT (NB2), NB-IoT (NB1)

Region

Global *

All Technical Details

Variant description

Contact sales@techship.com for more information

≥ 1

$19.60

Download Datasheet

Product Details & Tech Facts

Description

The Cinterion® TX62 IoT Module delivers global LTE-M, NBIoT (NB1 and NB2) connectivity from a single SKU and it is the first product to adopt the revolutionary “Things” footprint. The compact form factor has been engineered to facilitate the design of small, battery-operated LPWA cellular devices such as small payment terminals, connected sensors, track and trace solutions, meterings application, monitoring for smart homes, cities and agriculture

The highly efficient Cinterion TX62 delivers global LPWAN LTE connectivity from a single SKU leveraging mature Rel. 14 second generation Cat. M1/NB1/NB2. The ultraintegrated IoT module’s unique architecture allows the flexibility to run applications with a host processor or inside the module itself using the integrated processor dedicated to customer application for onboard processing, which optimizes the size and cost of your solution.

TX62 supports optimized 3GPP power modes PSM and eDRx revolutionizing design possibilities for battery-operated cellular devices. State of the art security features include trusted identities pre-integrated in the root of the module during manufacturing plus secure key storage and certificate handling to protect the device and data and enable trustful enrollment in cloud platforms. An optional integrated eSIM further simplifies manufacturing and logistics while providing flexibility in the field with easy remote provisioning and dynamic subscription updates. All this combined to Integrated GNSS support (GPS/Galileo/ GLONASS) provides a steady stream of timing and location information for precision positioning data anywhere in the world, making TX62 perfect also for small trackers devices..

Form Factor

LGA

Max UL Speed

1 Mbps

Certification

CE RED UKCA FCC IC PTCRB GCF RoHS REACH RCM IMDA Telec SRRC NCC KC Jate CCC

Driver Support

Linux

Primary Technology

eMTC (Cat-M1) NB-IoT (NB2) NB-IoT (NB1)

Antenna Connectors

Through pin

Extended Operating Temperature Range

-40 - 85 °C

Size

20.9x15.3x2.28 mm

Region

Global *

GNSS

Yes

Carrier Certification

Telstra

Chipset

Qualcomm MDM9205

LTE Bands

B1 (FDD 2100) B2 (FDD 1900) B3 (FDD 1800) B4 (FDD 1700 / AWS) B5 (FDD 850) B8 (FDD 900) B12 (FDD 700ac) B13 (FDD 700c) B14 (FDD 700PS) B18 (FDD 800) B19 (FDD 800) B20 (FDD 800DD) B25 (FDD 1900) B26 (FDD 850) B27 (FDD 800) B28 (FDD 700) B66 (FDD 1700 / AWS-3) B71 (FDD 600) B85 (FDD 700)

Voice Call Support

No

Max DL Speed

0.588 Mbps

GNSS technology

GPS GLONASS Galileo BeiDou

Operating Temperature Range

-40 - 85 °C

Data Interface

USB 2.0 Serial / UART SPI I2C
