Telit LE910-EU V2 LTE CAT-4, mPCIe
Article Number: 10639
|
Supplier Number: LEPCIEU2006T001000
|
End of Life
Brand
Telit Cinterion
Form Factor
mPCIe - full size
LTE Bands
B1 (FDD 2100), B3 (FDD 1800), B7 (FDD 2600), B8 (FDD 900), B20 (FDD 800DD)
Region
Europe
All Technical Details
Discontinued
Discontinued
Variant description
Product Details & Tech Facts
Description
Telit LE910-EU V2 LTE CAT-4 is a miniPCIe data-card designed for devices with high data throughput but small form factor requirements. It's target frequency band region is Europe and has both 3G/UMTS and 2G/GSM/GPRS fallback and is compliant with 3GPP Release 9. The fully certified LE910-EU V2 is easy to integrate with peripherals using USB 2.0 HS.
The mini PCIe form factor has become a popular standard adopted by connected device manufacturers to easily integrate wireless connectivity into devices for commercial and industrial markets, in mobile computing, kiosks and electronics in general.
Key Benefits:
Standard Mini PCIe Data-card form factor.
Increased connectivity performance with MIMO 2x2.
Ideal for m2m applications and devices with compact design and extended operating temperature range requirements.
Internet friendly with integrated TCP/IP and UDP/IP stacks.
LTE technology interchangeable with HSPA+ or EV-DO counterpart Telit miniPCIe modules.
Rx diversity allows end-device to be equipped with two cellular antennas improving the quality and reliability of the wireless connectivity.
Over-the-Air firmware update.
Battery-friendly 1.8V GPIO.
Form Factor
UMTS Bands
Antenna Connectors
Data Interface
Size
LTE Bands
GNSS
No
Chipset
SIM interface
Region
GSM/EDGE Bands
Certification
Audio interface
Primary Technology
Max DL Speed
150 Mbps
Operating Temperature Range
-40 - 85 °C
Voice Call Support
No
Fallback
Max UL Speed
50 Mbps
Extended Operating Temperature Range
-40 - 85 °C
Driver Support
