Telit LM960A18 LTE CAT-18 mPCIe

Article Number: 11045

|

Supplier Number: LM960AIW208T0WA000

|

End of Life

Brand

Telit Cinterion

Form Factor

mPCIe - full size

Primary Technology

LTE - cat 18

LTE Bands

B1 (FDD 2100), B3 (FDD 1800), B7 (FDD 2600), B8 (FDD 900), B12 (FDD 700ac), B13 (FDD 700c), B14 (FDD 700PS), B20 (FDD 800DD), B25 (FDD 1900), B26 (FDD 850), B28 (FDD 700), B29 (SDL 700), B30 (FDD 2300), B32 (SDL 1500), B38 (TDD 2600), B39 (TDD 1900), B40 (TDD 2300), B41 (TDD 2500), B42 (TDD 3500), B43 (TDD 3600), B46 (TDD 5200), B48 (TDD 3600), B66 (FDD 1700 / AWS-3), B71 (FDD 600)

All Technical Details

Variant description

Factory loaded firmware images and configs:
- Generic 32.00.118
- Verizon 32.00.128
- ATT 32.00.148
- TMO/Canada 32.00.158

≥ 1

$270.40

Download Datasheet

Product Details & Tech Facts

Description

The Telit LM960A18 Mini PCIe (mPCIe) data card delivers high speed data rates via Advanced LTE and offers a cellular connection for products in network appliance environments. This data card is well-suited for products that demand high throughput such as routers, mobile gateways and access points, to provide the most advanced 4G LTE connectivity, ensuring a rich and seamless user experience.

Based on LTE UE category 18, the LM960A18 mPCIe data card achieves download rates up to 1.2 Gbps and upload rates of 150 Mbps.

It supports up to 5x downlink carrier aggregation and 2x uplink carrier aggregation, 2x2 MIMO (4x4 MIMO on a set of bands). Please refer to the LM960 Hardware Guide for complete specification. The product supports multiple RF frequency bands and band combinations to accommodate global deployments.

Please note:
Refer to the AT commands guide for Telit LM960A18 and command AT#FIRMWARE for details on how to select active firmware. The Generic firmware config should be used with the majority of network operators and enables support of all frequency bands, while a few network carriers, such as AT&T, T-Mobile and Verizon in the US, should be used with their specific config to comply with the local regulatory, industry and carrier requirements.

Form Factor

mPCIe - full size

UMTS Bands

B1 (2100) B2 (1900) B4 (AWS) B5 (850) B8 (900)

Antenna Connectors

IPEX MHF-4

Extended Operating Temperature Range

-40 - 85 °C

SIM interface

Through miniPCIe connector Dual SIM interface

Primary Technology

LTE - cat 18

Max DL Speed

1200 Mbps

GNSS technology

GPS GLONASS Galileo BeiDou

Carrier Certification

AT&T T-Mobile Verizon US Cellular Telus NTT DOCOMO

Driver Support

Windows 10 Linux in kernel

LTE Bands

B1 (FDD 2100) B3 (FDD 1800) B7 (FDD 2600) B8 (FDD 900) B12 (FDD 700ac) B13 (FDD 700c) B14 (FDD 700PS) B20 (FDD 800DD) B25 (FDD 1900) B26 (FDD 850) B28 (FDD 700) B29 (SDL 700) B30 (FDD 2300) B32 (SDL 1500) B38 (TDD 2600) B39 (TDD 1900) B40 (TDD 2300) B41 (TDD 2500) B42 (TDD 3500) B43 (TDD 3600) B46 (TDD 5200) B48 (TDD 3600) B66 (FDD 1700 / AWS-3) B71 (FDD 600)

Data Interface

USB 3.0 USB 2.0

Region

Europe North America Asia Australia APAC

GNSS

Yes

Certification

CE RED FCC IC PTCRB GCF RoHS RCM Telec NCC Jate

Chipset

Qualcomm MDM9260

Fallback

3G

Max UL Speed

150 Mbps

GNSS antenna support

Passive Active

Operating Temperature Range

-40 - 85 °C

Voice Call Support

No
