5G sub6/LTE/UHF antenna adhesive, 15cm MHF-4L

Article Number: 11300
Brand: 2J Antennas
Supplier number: 2JP1180P-015MC137B-M

5G sub6/LTE/UHF antenna adhesive, 15cm MHF-4L

This is a rigid fiberglass self-adhesive antenna designed to provide optimal performance and simplified device integration catered to all global standards. Combining the new 5GNR technology with UHF (ultra high frequency) makes this omni-directional antenna the first choice for mobile devices, two-way radios, cellular and portable wireless devices that operate within 5GNR, 4G, 3G and 2G technologies.

This antenna is designed with ultra-thin dimensions of 155 x 19.5 x 0.2mm and with strong adhesive mounting allowing for easy installation to the inside of plastic housings where space is restricted, including side walls.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Connector Type
IPEX MHF-4
Technology / Antenna Frequency
410-496 MHz
617-960/1427-2690/3300-5000/5150-5925 MHz
Antenna Location
Internal
Mounting method
Adhesive
Impedance
50 Ohm
Cable length
15 cm
Cable Specification
1.37mm coax
Polarization
Linear
Radiation pattern
Omnidirectional
Max power
25 W
Operating Temperature Range
-40 °C – 85 °C
Width
19.5 mm
Length
155 mm
