5GNR MIMO,+ GNSS, 5in1 antenna, 3M, magnetic mount

Article Number: 11794
Brand: 2J Antennas
Supplier number: SI313100160

The Next-Gen Most Robust 5-in-1 5GNR MIMO and GPS/GNSS Solution for Worldwide Connectivity

The 5-in-1 combination ultra wideband magnetic mount antenna combines 4 x 5GNR MIMO with 1 x GNSS. This omni-directional antenna enhances mobile broadband (eMBB) with high performance and ultra-reliable low-latency communication (URLLC) with 360-degree clear signal strength and maximizes throughput making it ideal for next-generation MIMO devices, base station technology, and carrier aggregation (CA). This antenna is designed to improve signal strength allowing uninterrupted connectivity, better signal quality, and reliability while providing increased data throughput. These features make it an ideal candidate for the next generation of mobile services which involve high safety applications such as critical communications, police, ambulance, fire services, and other crucial connectivity.

Cables 1-4: 5GNR MIMO

Cables 1-4 are designed for 5GNR devices that operate within all  5GNR, 4G LTE, FirstNet, CBRS, LPWA, low-power wide-area (LPWA), CAT-X, CAT-Mx, CAT-NBx, Narrow Band-IoT, 3G and 2G standards (617 – 5925 MHz). All cables are designed with an omni-directional radiation pattern and linear polarization for maximum signal strength and throughput.

Cable 5: GNSS

Cable 5 is designed for precision navigational applications that operate within GPS and GLONASS standards.

This antenna comes with 3M cable length and SMA-M connectors on all cables.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Technology / Antenna Frequency
617-960/1427-2690/3300-5000/5150-5925 MHz
GLONASS 1598-1610
GPS 1575.42
Antenna Location
Outdoor
External
Mounting method
Magnetic
Connector Type
SMA-M
Impedance
50 Ohm
Cable length
300 cm
Cable Specification
LL195
LL100
Polarization
Linear
RHCP (GPS)
Radiation pattern
Omnidirectional
Max power
25 W
IP Class
IP69
IP67
IK09
Operating Temperature Range
-40 °C – 85 °C
Height
102 mm
Diameter
96 mm
Active/Passive GPS
Active

Datasheet for #11794 2j7084mgfc
