Fibocom L850-GL-10 LTE CAT-9 M.2

Article Number: 10918
Brand: Fibocom
Supplier number: FIBOCOM L850-GL-10 L

Fibocom L850-GL is an LTE CAT-9 M.2 module that supports LTE-FDD/
LTE-TDD and WCDMA bands.

This is a global module that is widely used in consumer electronics such as Laptops, Tablets and the gateway industry.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

We suggest Fibocom FM101-EAU LTE Cat-6 M.2
as replacement for this module.

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Region
Europe
North America
China
Japan
Africa
APAC
Primary Technology
LTE - cat 9
Form Factor
M.2 3042
LTE Bands
B1 (FDD 2100)
B2 (FDD 1900)
B3 (FDD 1800)
B4 (FDD 1700 / AWS)
B5 (FDD 850)
B7 (FDD 2600)
B8 (FDD 900)
B11 (FDD 1500)
B12 (FDD 700ac)
B13 (FDD 700c)
B17 (FDD 700bc)
B18 (FDD 800)
B19 (FDD 800)
B20 (FDD 800DD)
B21 (FDD 1500)
B26 (FDD 850)
B28 (FDD 700)
B29 (SDL 700)
B30 (FDD 2300)
B38 (TDD 2600)
B39 (TDD 1900)
B40 (TDD 2300)
B41 (TDD 2500)
B66 (FDD 1700 / AWS-3)
UMTS Bands
B1 (2100)
B2 (1900)
B8 (900)
B4 (AWS)
B5 (850)
Max DL Speed
450 Mbps
Max UL Speed
50 Mbps
Antenna Connectors
IPEX MHF-4
Certification
PTCRB
CE RED
FCC
GCF
CCC
Carrier Certification
Vodafone
NTT DOCOMO
AT&T
Operating Temperature Range
-20 °C – 65 °C
Data Interface
USB 3.0
USB 2.0
Driver Support
Linux
MIMO (Multiple-Input Multiple-Output)
Yes
Size
30x42x2.3 mm
Datasheet for Fibocom L850-GL LTE CAT-9 M.2 module

Download

Uploaded at
2019-04-25 14:48:34
Last updated
2019-04-25 14:48:34
Related products
Fibocom L850-GL-10 LTE CAT-9 M.2
Document describing the hardware specifications and integration related topics.

Download

Uploaded at
2019-10-14 13:50:22
Last updated
2020-05-13 15:55:28
Version
Fibocom L850-GL Hardware User Manual V1.1.4
Related products
Fibocom L850-GL-10 LTE CAT-9 M.2
This manual introduces the AT commands of Fibocom’s product L850 GL, and describes how the users can communicate with the devices using these commands. It describes the specification of syntax and parameters of the listed AT commands.

Download

Uploaded at
2020-05-13 16:05:45
Last updated
2020-05-13 16:05:45
Version
R1.1
Related products
Fibocom L850-GL-10 LTE CAT-9 M.2
This guide describes the Fibocom L8 series cellular modules supported AT commands

Download

Uploaded at
2019-10-14 13:45:31
Last updated
2019-10-15 16:46:30
Version
V2.0.2
Requirements
Fibocom L850 series
Fibocom L830 series
Related products
Fibocom L850-GL-10 LTE CAT-9 M.2
System Driver Integration and Application Guidance document for the Fibocom L8 Family series.

Download

Uploaded at
2019-10-14 14:07:53
Last updated
2019-10-14 14:07:53
Version
V2.0.0
Related products
Fibocom L850-GL-10 LTE CAT-9 M.2
Fibocom L860-GL-10 LTE CAT-16 M.2
Application Note about frequency band lock and RAT order definition for Fibocom L850-GL and L860-GL Series.

Download

Uploaded at
2019-10-15 15:55:28
Last updated
2019-10-15 15:55:28
Version
V.1.0.0
Related products
Fibocom L860-GL-10 LTE CAT-16 M.2
Fibocom L850-GL-10 LTE CAT-9 M.2
Application Note for the Fibocom L850-GL and L860-GL series modules about NCM connection establishment command AT+XDATACHANNEL Commands.

Download

Uploaded at
2019-10-14 14:32:05
Last updated
2019-10-14 14:32:05
Version
1.0.0
Related products
Fibocom L860-GL-10 LTE CAT-16 M.2
Fibocom L850-GL-10 LTE CAT-9 M.2
Question

How to collect initial diagnostics data and logs for Fibocom cellular modules needed when requesting Techship technical support?

Solution

In order to ease the troubleshooting of technical problems and understand your end-product or application and its usage scenario we ask you to please provide the following information when creating a technical support ticket at: techship.com/technical_support/

Please give a detailed problem description and in what precise circumstances it is present.

Describe the host system:
-Hardware (system board, processor architecture, other peripheral devices...)
-Operating system with detailed versions (E.g. Windows version and build, Linux distribution, kernel version)
-Drivers used and versions (Linux: out-of-tree vendor drivers or in-kernel drivers?)

Details from the cellular module label:
-Model
-SKU/BOM or P/N code
IMEI number

For Linux systems, capture terminal logs from commands:
uname -a
lsusb
lsusb -t
ifconfig -a
ls -l /dev/serial/by-id
ls -l /sys/bus/usb-serial/devices
dmesg

The cellular module logs can be acquired by accessing one of the USB enumerated serial (COM) interfaces or physical UART serial interfaces accepting AT commands. In Windows device manager they are generally found as modem infterface or serial and ports interface types).

Send AT commands to module and capture the text output:
Test that you get a OK reply:
AT
Enable AT command echo:
ATE1
Verbose error reporting:
AT+CMEE=2
Module model:
AT+CGMM
Firmware version:
AT+CGMR
IMEI Code:
AT+CGSN
USB endpoint configuration:
AT+GTUSBMODE?
Serial port configuration:
AT+GTUSBMODE=?
Operational mode:
AT+CFUN?
Selected network access techniques:
AT+WS46?
List network operator info:
AT+COPS?
Network registration status:
AT+CREG?
AT+CGREG?
AT+CEREG?
Signal strength:
AT+CSQ
Signal quality parameters:
AT+CESQ
List APN details:
AT+CGDCONT?
List Packet switch enable/disable status:
AT+CGATT?
List PDP profiles status:
AT+CGACT?
List bearers and IP addresses:
AT+CGCONTRDP=
AT+CGPADDR=
Check Temperaure:
AT+MTSM?
Check SIM status:
AT+GTUSIM?
Selected radio access technology:
AT+GTRAT?
Selected RAT and active frequency band(s):
AT+GTACT

For modems supporting 5G
List CA information:
AT+GTCAINFO?
