Huawei EM820W - 3G/GPS/HSPA+ Mini PCI Express Card - 21Mbps

Article Number: 10020
Manufacturer: Huawei
Supplier number: 51070GLX

The Huawei EM820W is a HSPA+ wireless data module with support for Quad-band UMTS/HSPA+ and Quad-band GSM/GPRS/EDGE networks.

EM820W is in compliance with the standard Mini PCI-e form factor and is easily integrated into applications such as notebooks, netbooks and tablets including M2M and other embedded solutions.

The EM820W also provides standalone as well as Assisted GPS including GPS XTRA.

End-of-life

Quantity Sample Price
≥ 1 $39.00
≥ 1 €35.90

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
UMTS Bands
B1 (2100)
B2 (1900)
B26 (850)
B8 (900)
GSM/EDGE Bands
B5 (850)
B8 (900)
B3 (1800)
B2 (1900)
Manufacturer
Huawei
Form Factor
mPCIe - full size
Technology
HSPA+
Antenna Interface
IPEX MHF/U.FL
GPS
Yes
GNSS technology
GPS
Max DL Speed
21 Mbps
Max UL Speed
5.76 Mbps
Chipset
Qualcomm
MDM8200A
Operating Temperature Range
-20 °C – 70 °C
Driver Support
Windows 7
Windows XP
Windows Vista
Linux
Android
Interface
USB 2.0
Voice Call Support
No
GNSS antenna support
Passive
GPIO
No
Certification
FCC
CE
CCC
RoHS
GCF
PTCRB
IC
Technical details:
This module will be shipped with the firmware 11.810.10.33.00 and BOM code 51070FGB.

This document mainly describes the power supply design for Huawei modules. This document also provides Huawei modules' requirements for power supplies, which can be used as reference for designing power supplies for Huawei modules. This document is composed of four chapters:

Power Supply Requirements
Power Supply Design Requirements
External Power Supply Circuits
Recommendations for the Layout and Routing of External Power Supply Circuits

Download

Datasheet for Huawei EM820W. This document includes an overview of EM820W and it's features. For more detailed technical information, see the Huawei EM820W Hardware Guide.

Download

Uploaded at
2012-07-12 13:19:35
Last updated
2015-09-24 19:48:16
Related products
Huawei EM820W

This document describes how to use EM820W together with various development boards.

Download

Uploaded at
2012-07-02 19:44:42
Last updated
2015-09-24 19:41:22
Version
02
Related products
Huawei EM820W

This document describes the AT commands that can be used with Huawei EM820W.

Download

Uploaded at
2012-07-02 19:43:08
Last updated
2015-09-24 19:41:11
Version
02
Related products
Huawei EM820W

Describes the hardware of Huawei EM820W.

Download

Uploaded at
2012-07-02 19:40:31
Last updated
2015-09-24 17:21:17
Version
06
Related products
Huawei EM820W

This archive contains certification documents for Huawei EM820W. Includes CE Certificate, EMC Reports, RF Reports and Safety Report.

Download

Uploaded at
2012-09-19 12:13:05
Last updated
2015-09-24 19:35:22
Related products
Huawei EM820W

Windows drivers for Huawei wireless modules.

Download

Uploaded at
2012-08-28 14:46:02
Last updated
2016-12-30 10:33:49
Version
4.25.43.04
Requirements
Windows XP/Vista/Win7
Related products
Huawei EM770w
Huawei EM680 Gobi 3000
Huawei EM820W
Huawei MC323
Huawei MG323-B LCC Development Kit
Huawei MG323-B Rev. V1R1
Huawei MG323 Rev. V1R1
Huawei MG323 Rev. V1R3

Connection management software for use in Windows with Huawei Device wireless modules.

Download

This is a firmware updater for the EM820W module.

Download

Uploaded at
2013-06-25 10:53:52
Last updated
2015-09-24 19:19:15
Version
01
Related products
Huawei EM820W

This is the release notes that come with the 11.810.10.03.00 firmware version of the EM820W

Download

Uploaded at
2013-06-25 10:58:22
Last updated
2015-09-24 19:19:01
Version
01
Related products
Huawei EM820W

This archive contains the Huawei EM820W Firmware V11.810.10.19.00 Updater Tool for Windows and the related release notes.

Download

Uploaded at
2017-04-11 13:31:55
Last updated
2017-04-11 13:31:55
Version
V11.810.10.19.00
Requirements
Microsoft Windows
Related products
Huawei EM820W

Huawei EM820W Firmware Updater 11.810.10.09.00 for Windows and Linux, release notes included.

Download

Uploaded at
2014-12-01 13:48:24
Last updated
2015-09-30 14:15:09
Version
11.810.10.09.00
Requirements
Windows, Linux
Related products
Huawei EM820W
