jjPlus WMU6202 is a dual band Wifi + Bluetooth combined half-size miniPCIe module fully based on USB2 as data interface for both Wifi and Bluetooth. It supports the wifi standards 802.11ac/a/b/g/n and MU-MIMO antenna technique and Bluetooth standards up to version 4.2.
jjPlus WMU6202 uses the Realtek RTL8822BU chipset.
Data sheet for jjPlus WMU6202 wifi module
This archive contains the JJPlus WMU62xx series wifi and bluetooth driver for Microsoft Windows.
Connector Type: 9-pin USB | Cable length: 30 cm | Operating Temperature Range: -25 °C – 70 °C | Width: 40 mm | Interface: USB 2.0 | Length: 90 mm | Height: 7 mm
1 PCS PRICE $37.30
Technology / Antenna Frequency: GSM 850/900/1800/1900, UMTS 2100, LTE 790-960/1710-2690 | Mounting method: Connector | Antenna Location: External | VSWR: 2.5 :1 | Gain: 5 dBi | Connector Type: SMA-M | Impedance: 50 Ohm | Polarization: Vertical | Radiation pattern: Omnidirectional | Max power: 50 W | Length: 195 mm | Diameter: 12.8 mm
1 PCS PRICE $6.00
