jjPlus WMU6204 USB type-A Wifi 2.4/5.0GHz Bluetooth card

Article Number: 10863
Brand: Emwicon
Supplier number: C-10-WMU6204

jjPlus WMU6204 is a dual band Wifi + Bluetooth combined USB type-A card fully based on USB2 as data interface for both Wifi and Bluetooth. It supports the wifi standards 802.11ac/a/b/g/n and MU-MIMO antenna technique and Bluetooth standards up to version 4.2.

jjPlus WMU6204 uses the Realtek RTL8822BU chipset.

The range of this module series is:
11073, jjPlus WMI6201 WiFi+BT USB dongle
10861, jjPlus WMU6202 miniPCIe - USB - WIFI2.4/5.0GHz Bluetooth
10862, jjPlus WMU6203 M.2 2230 USB Wifi 2.4/5.0GHz Bluetooth
10863, jjPlus WMU6204 USB type-A Wifi 2.4/5.0GHz Bluetooth card
10864, jjPlus WMU6205 4-pin USB Wifi 2.4/5.0GHz Bluetooth card
10928, jjPlus WMU6206 USB type-A Wifi 2.4/5.0GHz BT card (PCB antenna)
10927, jjPlus WMU6207 4-pin USB Wifi + Bluetooth card (PCB antenna)

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
AP/Client Mode
Client mode
Wifi Standard
802.11a/b/g/n/ac/ac wave 2
Wifi Frequency
2.4 GHz
5 GHz
Bluetooth Standard
Bluetooth 4.2
Form Factor
USB
USB type A
Data Interface
USB 2.0
Data Streams
2T2R MIMO
Driver Support
Linux
Windows
Windows 10
Windows 8.1
Windows 7
Max output power
15 dBm
Chipset
Realtek
RTL8822BU
Certification
CE RED
FCC
IC
RCM
NCC
ACMA
Operating Temperature Range
-20 °C – 70 °C
Extended Operating Temperature Range
-20 °C – 70 °C
Antenna Connectors
IPEX MHF/U.FL
MIMO (Multiple-Input Multiple-Output)
Yes
Data sheet for the jjPlus WMU6204 Wifi module

Download

Uploaded at
2019-03-01 14:13:45
Last updated
2019-03-27 10:33:45
Version
20181108
Related products
jjPlus WMU6204 USB type-A Wifi 2.4/5.0GHz Bluetooth card
This archive contains the JJPlus WMU62xx series wifi and bluetooth driver for Microsoft Windows.

Download

Uploaded at
2019-08-23 13:46:01
Last updated
2019-08-23 13:46:02
Version
08/2019
Requirements
Microsoft Windows 7 x64
Microsoft Windows 7 x86
Microsoft Windows 8.1 x64
Microsoft Windows 8.1 x86
Microsoft Windows 10 x64
Microsoft Windows 10 x86
Related products
jjPlus WMU6207 4-pin USB Wifi + Bluetooth card (PCB antenna)
jjPlus WMU6205 4-pin USB Wifi 2.4/5.0GHz Bluetooth card
jjPlus WMU6204 USB type-A Wifi 2.4/5.0GHz Bluetooth card
jjPlus WMU6203 M.2 2230 USB Wifi 2.4/5.0GHz Bluetooth
jjPlus WMU6202 miniPCIe USB Wifi 2.4/5.0GHz Bluetooth
Question

How can I control my Bluetooth devices on linux?

Solution

The easiest way of controlling Bluetooth devices on a Linux host is by using the Bluez package which can be found at the below link: https://github.com/bluez/bluez

It is natively supported from kernel 4.4 and by installing the bluez-utils package you can use the command line tool, bluetoothctl for configuring and pairing your Bluetooth.

Make sure that the bluetooth.service is running on your host device which can be checked with the command,

$ sudo systemctl status bluetooth.service

and started with,

$ sudo systemctl start bluetooth.service

In addition, make sure that the drivers are properly installed and loaded. Sometimes, WiFi drivers only include drivers for WLAN over PCI and an additional set of drivers are needed for Bluetooth to function in parallell over USB.

The package can support earlier kernel verision by backporting the package which supports the below basic features:

3.13 basic bluetooth classic and LE functionality

3.10 basic bluetooth classic

For basic troubleshooting, the Arch Linux wiki has a thorough guide at the following link:

https://wiki.archlinux.org/title/bluetooth#Troubleshooting
