LTE, WiFi MIMO, GNSS Antenna, Coach GLHPD

Article Number: 10988
Supplier number: GLHPDLTEMIMO-SF-MM

This Coach antenna provides optimal 4G LTE and dual-band 802.11ac Wi-Fi coverage in a single, low-profile housing. GLHPDLTE-MM also incorporate PCTEL’s unique high rejection GPS/GLONASS technology for optimal performance and support of carrier voice and data networks.

Proprietary filtering design allows wideband coverage while achieving superior out-of-band ejection for all GNSS frequencies. The antenna is made to be magnetically mounted using heavy-duty internal rare earth magnets with rubber pad on the bottom of the antenna prevents slippage and protects the mounting surface.

This PCTel antenna comes with an UV resistant IP67 compliant design which provides maximum protection against water or dust ingress under severe environmental conditions. The high performance, low loss cable and high-quality connectors provides maximum RF
system efficiency.

The Minimum Order Quantity for this item is 10 pcs. For other quantity please contact sales@techship.com .

The Coach antennas are available in different versions. Contact us for more information.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Sample Price

No prices available

For more information
please contact us at
sales@techship.com

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Technology / Antenna Frequency
Wifi/Bluetooth 2400
Wifi 5000
GPS 1575.42
GLONASS
LTE 698-960/1710-2700 MHz
Combination Antenna
Mounting method
Magnetic
Antenna Location
Outdoor
External
VSWR
2 :1
Connector Type
SMA-M
RPSMA-M
Impedance
50 Ohm
Cable length
5.18 cm
Cable Specification
RG174
Pro-Flex Plus 195
Polarization
Vertical
Linear
Radiation pattern
Omnidirectional
Max power
50 W
IP Class
IP67
Operating Temperature Range
-40 °C – 85 °C
Height
9.2 mm
Diameter
13 mm
