Sierra Wireless HL7812 Cat-M/NB2 LGA

Article Number: 11420
Brand: Sierra Wireless
Supplier number: HL7812_1104871

Sierra Wireless HL7812 is a global LPWA module with 2G fallback offering ultra low power, small footprint and deep coverage

For battery-powered or low power deployments, Sierra Wireless’ HL7812 module supports 3GPP’s Release 14 features and offers best-in-class power consumption, high transmit power and the highest level of security from the edge to the cloud. This ensures field longevity and reduces the risk of your mission critical applications such as asset tracking, smart energy, smart cities and more.

Key Benefits
• LTE B8 with NAD to enable utilities in the US to deploy their own 900MHz private network.
• Improve indoor and underground coverage with class 3 (23 dBm) transmission power.
• Integrated GNSS receiver with Assisted GNSS enables tracking and location-based services.
• Tiny size of 15x18x2,4mm
• Best-in-class power efficiency
• Variant available with Octave all-in-one edge-to-cloud solution.

Developer kit for this module can be found here; 11386 - Sierra Wireless HL78 dev.kit

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Region
Europe
North America
Asia
Australia
South America
Africa
APAC
Latin America
Primary Technology
eMTC (Cat-M1)
NB-IoT (NB2)
Fallback
2G
Form Factor
LGA
LTE Bands
B1 (FDD 2100)
B2 (FDD 1900)
B3 (FDD 1800)
B4 (FDD 1700 / AWS)
B5 (FDD 850)
B8 (FDD 900)
B9 (FDD 1800)
B10 (FDD 1700 / AWS+)
B12 (FDD 700ac)
B13 (FDD 700c)
B17 (FDD 700bc)
B18 (FDD 800)
B19 (FDD 800)
B20 (FDD 800DD)
B25 (FDD 1900)
B26 (FDD 850)
B27 (FDD 800)
B28 (FDD 700)
B66 (FDD 1700 / AWS-3)
B85 (FDD 700)
GSM/EDGE Bands
B2 (1900)
B3 (1800)
B5 (850)
B8 (900)
Max DL Speed
0.59 Mbps
Max UL Speed
1.1 Mbps
GNSS
Yes
GNSS technology
GPS
GLONASS
Operating Temperature Range
-40 °C – 85 °C
Chipset
ALT1250
Sony
Altair
Data Interface
Serial / UART
GPIO
ADC
USB 2.0
GPIO
Yes
Size
15x18x2.4mm
Product Technical Specification for Sierra Wireless HL781x series modules.

Download

Uploaded at
2021-06-24 11:58:56
Last updated
2023-08-17 15:02:34
Version
R9
Related products
Sierra Wireless HL7812 Cat-M/NB2 LGA
Sierra Wireless HL7810 Cat-M/NB2 LGA
Development kit user guide for Sierra Wireless HL78xx series modules.

Download

Uploaded at
2021-05-20 14:35:12
Last updated
2021-05-20 14:35:12
Version
R3
Related products
Sierra Wireless HL7845 Cat-M/NB2
Sierra Wireless HL7810 Cat-M/NB2 LGA
Sierra Wireless HL7812 Cat-M/NB2 LGA
Sierra Wireless HL78 dev.kit

AT Command Guide for Sierra Wireless HL78xx series modules

Download

Uploaded at
2022-08-16 08:41:48
Last updated
2023-08-17 14:42:40
Version
R17
Related products
Sierra Wireless HL7812 Cat-M/NB2 LGA
Sierra Wireless HL7810 Cat-M/NB2 LGA
Sierra Wireless HL7845 Cat-M/NB2
Customer Process Guidelines for Sierra Wireless HL78xx series.

Download

Uploaded at
2021-06-24 12:00:48
Last updated
2023-08-17 14:44:46
Version
R5
Related products
Sierra Wireless HL7845 Cat-M/NB2
Sierra Wireless HL7812 Cat-M/NB2 LGA
Sierra Wireless HL7810 Cat-M/NB2 LGA
