Sierra Wireless HL8528

Article Number: 10522
Supplier number: 1102576 *

The Sierra Wireless HL8528 module is part of the HL Series offering unprecedented scalability between 2G, 3G, 4G and LPWA networks and is pin-to-pin compatible with all HL variants and the WP Series.

3G technology is proven, reliable, widely deployed, and offers greater longevity compared to 2G while remaining relatively inexpensive compared to deploying on 4G LTE networks.

This embedded module is ideal for IoT applications not requiring broadband connectivity such as point-of-sale or ATM terminals, building automation, rugged handhelds and toll collection to name a few.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Sample Price

No prices available

For more information
please contact us at
sales@techship.com

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
UMTS Bands
B2 (1900)
B5 (850)
GSM/EDGE Bands
B5 (850)
B2 (1900)
Manufacturer
Sierra Wireless
Form Factor
LGA
Antenna Interface
Pin
GPS
No
Max DL Speed
7.2 Mbps
Max UL Speed
5.76 Mbps
Operating Temperature Range
-40 °C – 85 °C
Driver Support
Windows 7
Linux
Android
Windows 8
Interface
USB 2.0
Serial / UART
GPIO
ADC
Carrier Certification
AT&T
Certification
FCC
PTCRB
IC
Size
22x23x2.5 mm

Mobile devices using 3G and LTE are equipped with a second receive antenna for improved performance.
This second antenna is required for receive diversity and MIMO.
These concepts, with their associated benefits, requirements and test possibilities, are described in this Application Note in a Q&A format.

Download

Datasheet for Sierra Wireless AirPrime HL series modules

Download

Uploaded at
2017-05-04 17:16:54
Last updated
2017-05-04 17:17:02
Related products
Sierra Wireless HL8518
Sierra Wireless HL8528
Sierra Wireless HL8548
Sierra Wireless HL8548-G

This archive contains the Sierra Wireless Android RIL library with related manuals and release notes.

Download

Uploaded at
2017-10-05 17:57:52
Last updated
2019-07-16 16:18:35
Version
Android RIL_V9.0.4.0_ARM_64_bin_Android RIL_V8.1.2_x86_64_bin
Requirements
The following Android versions are supported:
• x86
▪ 5.0 (Lollipop)
▪ 5.1 (Lollipop)
▪ 6.0 (Marshmallow)
▪ 7.1 (Nougat)
▪ 8.1 (Oreo)

• ARM
▪ 5.0 (Lollipop)
▪ 5.1 (Lollipop)
▪ 6.0 (Marshmallow)
▪ 7.0 (Nougat)
▪ 7.1 (Nougat)
▪ 8.0 (Oreo)
▪ 8.1 (Oreo)
▪ 9.0 (Pie)
