SIMCom SIM33ELA

Article Number: 10413
Brand: SIMCom
Supplier number: N/A

SIMCom SIM33ELA is a standalone GNSS module with an embedded linear antenna . Designed with MTK’s high sensitivity navigation engine, it allows you to achieve the highest levels of sensitivity, accuracy, and Time-to-First-Fix (TTFF) with the lowest power consumption. This compact SMT type solution with embedded antenna makes it easy to embed in your application.

Features
• Support GPS/GLONASS/Galileo/QZSS
• Support EASYTM self-generated orbit prediction
• Support EPOTM orbit prediction
• Support AGPS
• Support SBAS ranging (WAAS, EGNOS, GAGAN, MSAS)
• Support Jamming removing function
• Low-noise amplifier has been integrated

Also please see the developer board for this product 10445, SIMCom SIM33ELA Development kit.

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Form Factor
SMT
GNSS technology
GPS
GLONASS
Galileo
QZSS
Operating Temperature Range
-40 °C – 85 °C
GNSS antenna support
Integrated
Certification
CE
Size
14x9.6x2.15 mm

SIMCom SIM33ELA Datasheet

Download

Uploaded at
2016-07-07 10:25:59
Last updated
2020-03-18 08:56:14
