Telit EVK2 IoT Dev.board

Article Number: 10681
Brand: Telit Cinterion
Supplier number: 3990150502

NOTE This board does not include a module interface board / translation board (TLB) which needs to be bought separately.

The Telit Evaluation Kit (EVK2) provides a robust, future-proof and flexible environment to streamline application development for all Telit module families and cellular standards.

The motherboard includes the basic interfaces such as power input, SIM card holder, audio monitor outputs, RS-232, and USB; as well as a Reset button and power switch. The circuit implemented in the EVK2 motherboard is based on the recommended reference design for the module's peripheral components and I/O connections.

Adapter boards are available for all the different module families. Adapter boards for modules with board-to-board connectors may be used for development with a number of different target modules sharing the same form factor.

Key Benefits
- Develop and test applications for current and future cellular embedded modules including LTE (Cat NB1-Cat 6), GSM/GPRS, and legacy CDMA 1x/EV-DO module families via AT commands through serial ports
- Program or update module firmware and application software
- Develop, test, debug and improve application programs
- Implement applications (stand alone function) by executing scripts with an IoT AppZone equipped module without the need for an external microprocessor
- Develop a first-pass proof-of-concept device for a new application

End-of-life

This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at
sales-americas@techship.com

For larger quantities and complete pricing, please sign in or register

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
External Voltage
Yes
Datasheet for Telit EVK2 developer board

Download

Uploaded at
2018-07-06 17:37:08
Last updated
2021-11-17 17:12:28
Requirements


Related products
Telit EVK2 IoT Dev.board
Telit EVK2 Driver installation guide

Download

Uploaded at
2018-07-06 17:39:42
Last updated
2018-07-06 17:39:42
Related products
Telit EVK2 IoT Dev.board
Telit EVK2 User Guide

Download

Uploaded at
2018-07-06 17:38:28
Last updated
2018-07-06 17:38:28
Related products
Telit EVK2 IoT Dev.board
