Compliant with 3GPP Release 14 (Rel. 14), the ME910G1 LTE UE Cat M1/NB2 module enables increased power saving for IoT applications using Power Saving Mode (PSM) and extended Discontinuous Reception (eDRX). These features allow devices to wake up periodically and deliver only small amounts of data necessary before returning to sleep mode. Enhanced coverage, enabled by maximum coupling loss (MCL) of up to +15 dB/+20 dB, provides superior in-building penetration compared to earlier cellular LTE standards. LTE Cat M1/NB2 devices are optimized in cost, size and power consumption compared to higher UE categories. 3GPP Rel. 14 further improves these features by adding techniques to increase the data rate for LTE-M and NB-IoT.
The ME910G1 series is offered with global frequency bands configuration for global deployment. It supports dual-mode Cat M1/NB2 (NB-IoT) capability and 2G fallback
• Design once and deploy globally with the xE910 form factor family
• An ideal solution for global IoT applications such as smart metering, security and surveillance, point of sales, health monitoring, fleet management, asset tracking and wearables
• Compliant to 3GPP Rel. 14 Cat M1/NB2, tailored for IoT devices
Contact email@example.com for more information, MOQ's may apply.
Scope of this document is to give a description of some hardware solutions useful for developing a product with the Telit ME910G1 module.
This guide describes the Telit xE910 series shared surface mount LGA design.
This guide describes the Telit LM910G1, ME910G1 and ML865G1 cellular modules AT control commands available and supported
Scope of this document is to give an overview of AT commands related to the integrated GNSS engine, to provide some basic procedure for use it and about the concurrence of the WWAN and GNSS on the MDM9205 products.
This document describes the integration steps of the cellular modules USB endpoints in Linux systems.
The ME310G1/ME910G1/ML865G1 includes unique advanced features in order to support the PSM according to 3GPP Rel-12.
The aim of this document is the description of the suggested Application design to use this functionality.
This archive contains the Windows 10 WHQL certified Telit module drivers for both x86 and x64 system platforms.
Zip archive with Telit cellular modules USB drivers installers for Windows 7, 8.x, 10 both x86 and x64 system architectures (Non WHQL certified drivers).
This archive contains the Telit AT controller tool as well as XFP firmware update tool for Microsoft Windows systems.
It can be used to troubleshoot, test and command the Telit cellular module in a graphical interface.
How to collect initial diagnostics data and logs for Telit cellular modules needed when requesting Techship technical support?
In order to ease the troubleshooting of technical problems and understand your end-product or application and its usage scenario we ask you to please provide the following information when creating a technical support ticket at: techship.com/technical_support/
Please give a detailed problem description and in what precise circumstances it is present.
Describe the host system:
-Hardware (system board, processor architecture, other peripheral devices...)
-Operating system with detailed versions (E.g. Windows version and build, Linux distribution, kernel version)
-Drivers used and versions (Linux: out-of-tree vendor drivers or in-kernel drivers?)
Details from the cellular module label:
-SKU/BOM or P/N code
For Linux systems, capture terminal logs from commands:
ls -l /dev/serial/by-id
ls -l /sys/bus/usb-serial/devices
The cellular module logs can be acquired by accessing one of the USB enumerated serial (COM) interfaces or physical UART serial interfaces accepting AT commands. In Windows device manager they are generally found as modem infterface or serial and ports interface types).
Send AT commands to module and capture the text output:
Test that you get a OK reply:
Enable AT command echo:
Verbose error reporting:
USB endpoint configuration:
Serial port configuration:
Selected network access techniques:
List network operator info:
Network registration status:
Last serving cell network information:
Current network status:
List APN details:
List Packet switch enable/disable status:
List PDP profiles status:
List default data connection details:
List bearers and IP addresses:
Additional test commands for Telit LM940/LM960:
