Techship MP101-S Adapter (M.2 Key B - mPCIe, USB2, Dual SIM)

Article Number: 11315
Brand: Techship
Supplier number: MP101-S

Jumpstart your IoT development with this unique series of Techship premium adapters for 4G and 5G cellular modules.
In-house designed and EU manufactured to meet our requirements of high quality and to be compatible with most M.2 cellular modules. This is the most flexible adapter on the market.
Test the first generation of 5G sub-6 modules in your current design that supports mPCIe or integrate the module with adapter in your application when flexibility is necessary.

Key features
• Supports 4G and 5G Sub6 M.2 cellular modules. Three various designs to match different data signal interface between the cellular module and the host system.

• Jumpers included to activate or deactivate USB2/USB3 or PCIe data signal interface. Signal composition by default vary among manufacturers.

• Both sides of the PCB are prepared for heat absorption, by adding a thermal pad in the space between module and PCB. Recommended for highspeed modules.

• Ceramic capacitors with a combined capacitance of 470uF, improves voltage stability needed during full power radio frequency transmissions.

• Double SIMcard holder to access several operators.

Signal pinouts matching among others
Telit - FN980, LN920
Sierra Wireless - EM9191, EM7690, EM75XX, EM74XX
SIMCom - SIM8202, SIM8200, SIM7912, SIM7906, SIM7600
Fibocom - FM150, NL668
Quectel - RM505, RM502, RM500
Global and regional variants are included among examples.

Adapter family variants - data signal interface
MP101-S - USB2
MP201-S - USB2, USB3
MP301-S - USB2, PCI Express

Please observe!
When using generic 3rd party adapters with 5G cellular data card modules, always ensure compatibility for pin-out definitions, signal voltage level, and power output capabilities for your selected cellular module, the adapter and host board prior to using the adapters. Failure to do so can result in malfunctioning systems or hardware damage to the parts.


This product has reached
end-of-life and can not be
ordered any more.

Quantity Price

No prices available

For more information
please contact us at

For larger quantities and complete pricing, please sign in or register

Do you need offline data on this product?

Download datasheet

Subscribe to stay up to date with the latest about this product.

Subscribe to updates
Module KEY
Supported card lengths
Form Factor
mPCIe - half size
mPCIe - full size
Data Interface
USB 2.0
SIM interface
Nano (4FF) SIM-slot
Onboard slot-in card type
M.2 key B - 3052
M.2 key B - 3050
M.2 key B - 3042
M.2 key B
Datasheet for the Techship M.2 to miniPCIe adapters MP101-S, MP201-S, MP301-S.


Hardware guide for the Techship MP101-S, MP201-S, MP301-S series M.2 key B to miniPCIe adapter family.
